| General |
|---|
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n |
| Frequency Band | 2.4 GHz, 5 GHz |
| Data Transfer Rate | 300 Mbps |
| Network / Transport Protocol | NTP, ICMP/IP, SMTP |
| Routing Protocol | OSPF |
| Remote Management Protocol | Telnet, HTTP, HTTPS, SSH |
| Encryption Algorithm | TLS, TTLS, TKIP, WPA, WPA2, 128-bit AES |
| Features | NAT support, PAT support, VLAN support, DiffServ support, MAC address filtering, IP address filtering, wall mountable, Wi-Fi Multimedia (WMM) support, Access Control List (ACL) support, DHCP server, Multiple SSID support, bandwidth control, 2T2R MIMO technology |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11e, IEEE 802.11n , EN55022, IEC 60529 IP67, CSA 22.2 No. 60950, CB, EN 300.328, FCC Part 15, IC, FCC, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, cTUVus, IP66, EN 61000 |
| Status Indicators | Link activity, power, link OK |
| Line Properties |
|---|
| Line Coding Format | CCK, 64 QAM, BPSK, QPSK, 16 QAM, OFDM |
| Expansion / Connectivity |
|---|
| Interfaces | USB : 1 xWAN : 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45Antenna : 4 x N-Series connector |
| Power |
|---|
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Power Consumption Operational | 15 Watt |
| Miscellaneous |
|---|
| Mounting Kit | Included |
| Localization | United States |
| Software / System Requirements |
|---|
| OS Provided | Aruba MeshOS |
| Dimensions & Weight |
|---|
| Approximate Width | 10.2 in |
| Approximate Depth | 9.4 in |
| Approximate Height | 4.1 in |
| Approximate Weight | 9.5 lbs |
| Manufacturer Warranty |
|---|
| Service & Support | 1 year warranty |
| Service & Support Details | Limited warranty - parts and labor - 1 year |
| Environmental Parameters |
|---|
| Min Operating Temperature | 40 |
| Max Operating Temperature | 131 |
